The lighting fixtures are fully fitted to the keel and easy to install, with high-density sealing filling between the lamp body and the back cover. No dust accumulation, easy to clean, no glare, the back cover adopts a door opening design, fixed with high-quality buckles, easy to open and close, and easy to maintain. The overall dimensional error is less than+/-1mm, and the flatness meets JIS141.

Product Features:

Lamp body: Made of four fold steel plate with no radiation pollution, galvanized anti-static baking paint.
Load capacity: 255KG/㎡.
Lamp shade: impact resistant and anti-aging acrylic, milky white acrylic, transparent acrylic, prismatic plate and tempered glass can be selected.
Supporting light source: LED white light tube or UV resistant LED yellow light (filtering harmful spectra below 500nm).
Protection level: IP40/IP65
Product standards and technical requirements:

GB 17625.1-2022; GB/T 17743-2021;GB/T 7000.1-2023;GB/T7000.202-2023

Product Model	power(LED)	Lamp body dimensions( mm )	luminous flux（lm）	power factor
HR-MF 318	3×18W	1170×570×110	3×2600	0.95
HR-MF 418	4×18W	1170×570×110	4×2600	0.95
HR-MF 518	5×18W	1170×570×110	5×2600	0.95
HR-MF 318	3×20W（Amber）	1170×570×110	3×2500	0.95
HR-MF 418	4×20W（Amber）	1170×570×110	4×2500	0.95
HR-MF 518	5×20W（Amber）	1170×570×110	5×2500	0.95
